Type Name

FLEX100MD

FLEX120MD

FLEX200MD

FLEX240MD

Maximum Power (Wp)

100W

120W

200W

240W

Cell No.

MONO182 (3x10)

MONO182 (3x12)

MONO182 (3x15)

MONO182 (3x18)

Connection

Series

Series

Series

Parallel

Series

Parallel

Open circuit Voltage (Voc)

20.45

24.5

40.9

20.45

49

24.5

Short circuit Current (Isc)

6.25

6.25

6.25

12.5

6.25

12.5

Maximum Power Voltage (Vm)

17.2

20.6

34.4

17.2

41.2

20.6

Maximum Power Current (Im)

5.82

5.83

5.82

11.64

5.83

11.65

Maximum Series Fuse

10A

10A

10A

20A

10A

20A

18.36%

18.76%

19.24%

19.72%

Net Weight

1.3KG

1.6KG

2.45KG

2.9KG

Cables & Plug Connectors

2x1500mm / 2.5mm²

2x1500mm / 2.5mm²

2x2000mm / 2.5mm²

2x2000mm / 2.5mm²

Module Dimensions (L/W/H)

920x592x2mm

1080x592x2mm

1350x770x2mm

1580x770x2mm

2 in 1 Carton Dimensions (inner)

950x605x35mm

1110x605x35mm

1380x780x35mm

1610x780x35mm

Qty/20GP

2268pcs

1890pcs

1254pcs

990pcs

Number of Diode

1

2

Power Tolerance

±3%

Junction Box (Protection Degree)

≥IP67

Maximum System Voltage

600V/DC

+0.08558%/°C

-0.29506%/°C

-0.38001%/°C

Operating Temperature

-40°C...+85°C

Standard Test Conditions

1000W/M²,25°C,AM1.5

CE

Warranty

10 years'product warranty
